Ultrasonic Converters 20khz 110-3122a

Ultrasonic Converters 20khz Dukane hloov 110-3122

Specifications:

Qauv: HS-D 110-3122

Zaus: 20khz

Cov zis hluav taws xob: 2000 watt

Joint bolt: 1/2-20 UNF

Ceramic disc Diameter: 50mmQty ntawm ceramic discs: 4pcs Capacitance: 11-17 nfAmplitude: 20um

Daim ntawv thov: Yas vuam tshuab

Nqe lus piav qhia:
Lub 2000 Watt 20 KHz Ultrasonic Converter Direct hloov rau Dukane 110-3122 uas xa cov nqi qis, rugged zoo thiab superior nqi.

Cov duab ntxaws:

FAQ:

Q: Yuav ua li cas yog tias lub transducer thiab lub tshuab hluav taws xob tsis sib haum zoo?

A: Cov tswv yim sib piv yog hais txog kev sib txuam ntawm ultrasonic transducer thiab lub zog tsav tsheb. Yog tias cov zis sib txuam zoo thiab cov kev sib txuam tsis zoo, lub ultrasonic transducer tsis muaj zog thiab vuam tsis ruaj. Yog hais tias qhov kev sib piv ntawm cov zis tsis zoo thiab qhov kev sib piv ntawm cov khoom siv tau zoo, lub transducer yuav overloaded, ua rau wafer misalignment, tawg, tawg ntsia hlau, tawg aluminium, los yog tawg lub hwj chim lub thawv fais fab raj. Piv txwv li, ib yam li lub tsheb slams lub throttle nyob rau hauv ib tug nruab nrab lub xeev, lub cav yuav tsum tau yooj yim puas.

Q: Dab tsi yog qhov ua haujlwm kub ntawm transducer?

A: Raws li kev paub hauv tsev thiab txawv teb chaws, qhov kub ntawm transducer yuav tsum tsis txhob siab tshaj 85 degree txhua lub sijhawm. Peb yuav muab ib lub sij hawm, uas tsis yog-reversible kub-sensing thaj rau ntawm lub transducer. Ntev npaum li qhov ntsuas kub ntawm qhov ntsuas kub siab tshaj 85 degree, qhov ntsuas kub-rhiab yuav raug hloov pauv mus tas li, uas qhia koj tias tseem muaj qee qhov teeb meem nrog kev siv cov transducer. Yuav tsum ua tib zoo nrhiav qhov laj thawj ntawm qhov teeb meem.

Q: Tus qauv ntawm PZT transducer yog dab tsi?

A: Lub transducer muaj cov vaj tsev nyob, cov txheej txheem sib txuam, lub piezoceramic disc transducer, lub nraub qaum, ib qho kev tawm mus, thiab lub Cymbal array receiver.
